DS-3E1526P-EI 24 Port Gigabit Smart POE Switch HIKVISION
2,500.00 MAD
- 24 x gigabit PoE RJ45 ports, 1 × gigabit RJ45 port, 1 x gigabit fiber optical port
- Total PoE power budget 370 W
- Unified cloud management for security systems
- Network topology at your fingertips
- Remote troubleshooting
- Visualized topology management
- Up to 300 m long-range PoE transmission
- 6 kV surge protection
Description
- General
- ShellMetal material
- Net Weight3.1 kg (6.83 lb)
- Gross Weight3.3 kg (7.27 lb)
- Dimensions (W × H × D)440.0 mm × 220.8 mm × 44.0 mm (17.32 » × 8.69 » × 1.73 »)
- Operating Temperature0 °C to 45 °C (32 °F to 113 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply100~240 V AC, 50/60 Hz, Max. 6.3 A
- Max. Power Consumption400 W
- Power Consumption In Idle30 W
- Network Parameters
- Ports24 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z
- Working ModeStandard mode (default)
- MAC Address Table8 K
- Switching Capacity56 Gbps
- Packet Forwarding Rate41.66 Mpps
- Internal Cache4.1 Mbits
- PoE Power Supply
- PoE StandardIEEE 802.3af,IEEE 802.3at
- PoE Power Pin8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE PortPoE: Ports 1 to 24
- Max. Port Power30 W
- PoE Power Budget370 W
- Software Function
- Device MaintenanceRemote upgrade, default parameters recovery, basic network parameters configuration, import and export configuration, time sync
- Port ConfigurationPort rate configuration, slow control, and ports enabling
- PoE WatchdogPoE watchdog: Ports 1 to 24 auto detect and restart the cameras that do not respond.
- Port MirroringSupported
- Link AggregationStatic link aggregation supported for any four ports, and up to eight aggregation groups allowed
- Port IsolationPorts in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group
- LLDPLLDP protocol supported for port configuration, global configuration and neighbour discovery
- DHCPDHCP client
- MAC Address Table DisplaySupported
- Super IP10.180.190.200
- Cable DetectionSupported
- HPPSupported
- Port Long-Range ModeSupported
- Port StatisticsSupported
- Web ManagementSupported
- Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017); IC (ICES-003: Issue 6); RCM (AS/NZS CISPR 32: 2015)
- SafetyUL (UL 60950-1); CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
